Dongguan Jiayi Intelligent Equipment Co., Ltd. is a professional manufacturer specializing in linear modules, coordinate robots, linear motors, and electric cylinders. With mature technology, our branded products offer high cost-effectiveness and short delivery times! Contact Deng Sheng at 18822958970
The IL59 series of core-less linear motor modules offer the following advantages:
1. The core components are imported from Taiwan, including screw rods and guide rails.
2. The body adopts a new type of aviation aluminum material, which has higher rigidity and lighter weight.
3. High stability, high reliability, with an accuracy of up to 0.02mm.
4. Smooth operation, no wear and tear, minimal maintenance, long service life.
5. Compact size, space saving, easy to build.
6. The requirements for the motor are not high, and it can adapt to mainstream motors on the market.
Engineering one-on-one tailored selection, helping you save time and make products more superior.
